In this study, field instrumentation was used to assess the vibrational characteristics of a selected tracking photovoltaic support system. Using ANSYS software, a modal analysis and finite element model of the structure were developed and validated by comparing measured data with model predictions. Key findings are as follows.
While significant progress has been made by scholars in the exploration of wind pressure distribution, pulsation characteristics, and dynamic response of tracking photovoltaic support system, there is a notable gap in the literature when it comes to modal analysis of tracking photovoltaic support system.
In terms of finite element analysis, Wittwer et al., obtained modal parameters of the tracking photovoltaic support system with finite element analysis, and the results are similar to those of this study, indicating that the natural frequencies of the structure remain largely unchanged.
Because the support structure of the tracking photovoltaic support system has a long extension length and the components are D-shaped hollow steel pipes, the overall stiffness of the structure was found to be low, and the first three natural frequencies were between 2.934 and 4.921.
Recent research indicates that the dynamic characteristics of tracking photovoltaic support system, namely inertia, damping, and stiffness, significantly influence the tracking photovoltaic support system's ability to respond to wind-induced loads, affecting its stability, reliability, and overall performance , .
Key findings are as follows. Dynamic characteristics of tracking photovoltaic support systems obtained through field modal testing at various inclinations, revealing three torsional modes within the 2.9–5.0 Hz frequency range, accompanied by relatively small modal damping ratios ranging from 1.07 % to 2.99 %.
